MULTI-DIRECTIONAL PASSENGER COUNTING
- Count boarding and alighting passengers with the highest accuracy available in the market (Accuracy of at least 99 %)
- The APS-B fulfills VDV 457-2 accuracy requirements
- Up to 10 individual counting lines are possible per device
- Capture separate figures for interior doors, left and right side or upper and lower deck, without the need of additional units
- Detection and exclusion of U-turns
OCCUPANCY MONITORING IN AN AREA
- Real-time passenger detection to determine the occupancy of individual areas for optimized capacity planning
OBJECT CLASSIFICATION
- Separate counting results for adults and children
- Detection of bicycles and wheelchairs
VIDEO RECORDING FOR COUNT VERIFICATION
- Recording of color VGA video files alongside caption of measurement results
- Recording can be triggered via digital inputs (door contact)
- Privacy option: Individuals are not recognizable on videos
REAL-TIME DATA
- Very short latency time of 50 ms
- Start-stop detection using the integrated accelerometer
- Suitable for solutions that require an instant event-triggered activity, e.g. the reopening of a door if a passenger approaches
EASY SETUP AND COMMISSIONING
- Automatic determination of mounting angles
- Automatic determination of the floor profile and ceiling height
- Intuitive and straight-forward setup of all other parameters via the web user interface
- Instant full performance, no calibration required
- Easy demonstration to the end user using color videos with synchronized data records
TECHNICAL DATA
| Operating voltage | 12V DC to 24V DC (nom.) Protected against short-circuit and inverse polarity |
| Power consumption | 4 W |
| Operating temperature | ISO 16750-4 -15°C to +70°C (+5°F to +158°F) |
| Storage temperature | ISO 16750-4 -40 °C to +85 °C (-40 °F to +185 °F) |
| Ingress protection | IP30 |
| EMC | UN ECE R 10 EN 50498 |
| Shock and vibration | ISO 16750-3 |
| Coverage | Ceiling height: 2.00 m to 4.00 m (6.6 ft to 13.1 ft) Coverable door width: 1.60 m to 5.60 m (5.2 ft to 18.4 ft) depends on installation height |
| Dimensions | 136 mm x 79 mm x 31 mm (5.3 in x 3.1 in x 1.2 in) |
| Weight | 250 g (8.8 oz) |
| Housing | Aluminum and stainless steel |
| Light sensitivity | 3 Lux to 300,000 Lux High Dynamic Range (HDR) |
| Failure rate | < 2,000 FIT (= MTBF 500.000 h) |
| Type approvals | ECE type approval for road vehicles CE Declaration of Conformity |
INTERFACES
| Ethernet | 10/100/1,000 Mbit/s, full duplex |
| Communication protocols | TCP, UDP, FTP, HTTP, HTTPS, SOAP, VDV-300 (IBIS), VDV-301 (IBIS-IP), ITxPT, SSH |
| Inputs/outputs | 2 programmable digital inputs, 1 programmable digital outpu |
| Setup/service | Integrated web interface |
ACCESSORIES
| Generic mounting kits for surface mount, flush mount and variable tilt angles are available from stock |
